To make practical and economic use of the advantages of test connections, a series of automatic, computer-controlled mechanisms is required.

Flexible measurement sets make kyago a universal and future-proof tool. Routine works should not affect the user. The specialist should only be brought in in cases where professional knowledge and experience are really needed. kyago has taken account of these requirements in the concept.

Further details on the technical design and the quality characteristics are described in the kyago whitepaper.

We will be happy to send you the kyago whitepaper on request. If you are interested, just send us a e-mail.

Modern Talking?

The days of ISDN and classic telephony are numbered, as telecommunications providers are gradually converting all their networks to All-IP.

All-IP refers to the conversion of the transmission technologies previously used in telecommunications networks to a uniform IP-based system. The abbreviation IP stands for "Internet Protocol" and describes a communication technology on the Internet with which information can be transmitted digitally and packet-switched.

All-IP now enables telecommunications providers to provide customers with all services such as telephony, fax, TV, Internet and mobile telephony in a single network, the so-called Next Generation Network (NGN). For this purpose, an Internet connection is completely sufficient. A separate ISDN connection is no longer required.

Against the background of this development, the question of the experienced service quality is becoming increasingly important for All-IP.

Voice under the microscope

The end-to-end speech quality measurements of the kyago platform can be performed between measurement systems at various locations. To this end, connections are set up via end customer interfaces.

To determine the end-to-end voice quality of the respective connections, standard ITU-T voice samples of male and female voices are repeatedly transmitted in both communication directions and compared with the originals in the subsequent automated assessment process. The evaluation of speech quality is based on ITU-T standards.

As a further QoE aspect relevant for end customers, voice quality measurements can be performed at the same time as bandwidth utilisation of the respective product. For this, parallel to the voice quality measurement, larger data amounts are transferred from and to data reference systems and IPTV measurements initiated.

Highspeed or lame duck?

In today's age of digitalization, fast Internet is the basis for the business success of companies in many industries. This is why the most important providers are eagerly pushing ahead with the expansion of networks, the laying of fiber optic cables and the increase in Internet speed.

However, the information provided by the providers on speed must often be viewed as theoretical values in practice. The actual speed of a broadband connection often turns out to be much lower than booked. Above all, cable and DSL connections are always below the theoretically possible maximum when many users call up large amounts of data at the same time, for example through video streaming.

High-speed Internet under the microscope

To evaluate the quality of high speed Internet, various measurements can be performed with the kyago platform. The available upstream and downstream bandwidth is determined by standardised upload and download measurements which are made to data reference systems. These measurements are also carried out at the same time as download or upload in order to determine the behaviour of the products under simultaneous utilisation of the bandwidth. As further QoE indicators, among other things, packet times, the frequency of packet losses, and the time for DNS name resolution are measured.

All Cloud or what?

Even with large numbers of visitors and temporary sales promotions, customers expect optimal performance. Unsatisfied customers are caused by long loading times, sluggish music and video clips or unreachable websites.

Average users wait no longer than four seconds for a website to appear in full. 90 percent of Internet customers turn their backs on an online shop after three failed access attempts at the latest.

Cloud under the microscope

Even with large numbers of visitors and temporary sales promotions, customers expect optimal performance. Dissatisfied customers are the result of long load times, faltering music and video clips or unreachable sites.

Thekyago platform measures both performance-based QoS measurements such as the DNS resolution time and response times for gaming servers and user-oriented QoE measurements such as Kepler, website loading times and upload measurements for various photobook providers.

The use of DNS, as one of the most frequently used Internet services, is usually not noticed by the user. However, because this service is fundamental for interaction and a runtime delay affects a high number of Internet services, this measurement is carried out as an independent test.

A number of online games require above-average runtime performance to enable players to compete with other players on an equal footing in interactive games.

In the user-oriented QoE measurements, a website is accessed via a browser. Standardised test pages (ETSI Kepler reference page) from national and international webhosting-providers are accessed and measured at the transport layer.

In addition, various, frequently used websites are also measured at the application layer. The two leading browsers by market share in Germany (Firefox and Chrome) are used to determine the quality parameters. Key elements of the trigger points standardised according to W3C "Navigation Timing" are used to determine the measured values of website calls.

Totally streaming!

In 2022, the global video traffic will constitute up to 82% of end user traffic. Well over half of this is generated by Internet video portals such as YouTube, Amazon Prime, Netflix, Sky or media centres (source: Cisco Visual Network Index, 02.2019).

This presents a major challenge for Internet service providers if they want to provide excellent quality of service to their customers. They not only have to ensure quality of service in their own network, but also pay particular attention to the video content feed via various peerings and content delivery networks (CDN).

Streaming under the microscope

The streaming test carries out a measurement using the over-the-top approach for different video content providers. A Chrome web browser with the appropriate plug-ins needed for all the major components of the video being tested, is used to access the videos.

The streaming services measured use adaptive streaming. Depending on the provider, different streaming approaches are offered using MPEG-DASH, HLS or progressive download (HTML5 video), among others. Video containers with different video codecs such as H.264, HEVC/H.265, VP9 or AV1 and audio codecs such as MP3, AAC or Opus are used.

Quality analysis is carried out according to the ITU-T Rec. P.1203 standard, which supports HEVC/H.265, VP9 and AV1 as well as 4K/UHD-1 resolutions and frame rates of up to 60 FPS in addition to H.264 with extensions.

As part of the YouTube (YT) video response time measurements, ten videos are retrieved every hour in a Google Chrome browser and the time it takes for the first video segment to arrive from the content server is measured.

Totally TV!

In the age of modern network infrastructures and convergence to the Next Generation Network (NGN) or ALL-IP network, well-known services such as linear television, which has previously been aired by the TV stations on cable, satellite or terrestrial via broadcast, are now being ported via new transmission media.

The most common designation for television which is broadcast or received via the Internet is “Internet Protocol Television” (IPTV). IPTV generally designates the digital transmission of audio and video signals via a broadband Internet connection.

Through the broadband Internet connection, genuine interaction with the consumer is possible, through which new applications and services such as video-on-demand (VoD) can be realised.

IPTV under the microscope

In the increasingly complex world of next-generation video services, knowledge about the quality of service is a crucial factor in the fight for market share and customer satisfaction. It is precisely here that the research group data networks from the Cologne University of Applied Sciences and zafaco GmbH have developed quality measurement systems for IP-based audio/video services.

The subjective and objective quality of the media data is derived from the current IP data stream (live and non-reference measurements) and, alongside an analysis of the network parameters and the quality of service (QoS), it is based on an analysis of the video codec layer using “deep packet inspection”.

The evaluation of the quality of IPTV services from the perspective of the end customer is determined by measuring network parameters such as delay, jitter, packet loss according to RFC 3350 and RFC 3357 among others.

The evaluation also takes account of video quality parameters according to ETSI TR 101 290 and Broadband Forum TR-126 as well as MQS values (Media Quality Score) for the video and audio signals of the streams transmitted using the set-top box and its remote control.

Fast-zapping and error correction mechanisms according to RFC 5109 are also included in the quality assessment.

Networks in stress!

More and more applications are operated centrally in the data centre or migrate in the Cloud. Employees’ work is increasingly mobile and flexible. On top of this, there is voice over IP, unified communications and video.

In short, networks and applications are growing together. Here, top performance is required in the network.

Business applications under the microscope

The aim of our analysis is to identify problem areas in your ICT infrastructure and to develop a suitable optimisation strategy. Through continuous analysis, quality and performance control the of ICT infrastructure, the performance values can be called up almost in real time, as well as for specific intervals.


Key facts at a glance

  • Analysis of the application performance
  • Recognisability of application performance problems and their causes
  • Automatic notification when threshold values are set
